In this project, I introduce to you the Stagmeter 3000!!
The Stagmeter 3000 is a digital voltmeter that will read AC Current, AC Voltage, Resistance, and also has a tone generator. This short module gives you an opportunity to interact with the Stagmeter 3000 and an extension cord for helping to develop some basic voltmeter usage and concepts.
This project features:
Interactive voltmeter dial – you must rotate the dial to the desired setting.
Drag and Drop test leads
Digital readout
Homemade voltmeter, test leads, outlet, digital display, and extension cord graphics (PowerPoint crafted)
Error conditions / warnings so you do not do them with a real meter.
Error conditions must be corrected before continuing
Non-linear design
Thank you to all those who take the time to view the project.
The post Using a Digital Voltmeter appeared first on eLearning.
Interact with the Stagmeter 3000 to learn some basic voltmeter functions.
